RadiSys CEGM45T2-P84-0自动化控制模块

产品详细资料
五次谐波方案如果连接到继电器的任何电流信号的五次谐波含量在设定的时间内超过阈值设定，则五次谐波计划运行，前提是电平高于设定的阈值。 禁用除五次谐波功能外的所有保护功能。第五谐波方案设置在S4 ELEMENTS中 过励磁 第5谐波电平设定点菜单。此测试需要一个能够产生基波和五次谐波分量的电流发生器。 将电流信号连接到H1和G1，并将基本分量电平设置为高于阈值设置。 缓慢增加5次谐波分量的振幅，直到元件工作为止。 计算发生操作时的五次谐波与基波的比率，并将该值与元件的设置进行比较。 检查跳闸、拾取（以及如果选择报警）指示灯是否亮起，并显示以下其中一项：闭锁：5次谐波电平或操作：5次谐波电平 减少5次谐波分量，直到元件复位。复位电平应为操作电平的97%。 重置指示灯并清除信息。 在基本电流水平低于阈值设置的情况下重复上述步骤。 确保滤芯不工作。 对于定时测试，模拟如上所述的操作条件，并突然应用于继电器并测量操作时间。时间应该与元素中的设置相同。
Fifth Harmonic Scheme The 5th harmonic scheme operates if the 5th harmonic content of any current signal connected to the relay exceeds the threshold setting, for the set time, provided that the level is above the set threshold.  Disable all protection functions except the 5th harmonic function. The 5th harmonic scheme settings are in the S4 ELEMENTS  OVEREXCITATION  5th HARMONIC LEVEL setpoints menu. This test requires a current generator capable of producing a fundamental and 5th harmonic component.  Connect the current signal to H1 and G1 and set the fundamental component level above the threshold setting.  Slowly increase the amplitude of the 5th harmonic component until the element operates.  Calculate the ratio of 5th harmonic to fundamental at which operation occurred and compare this value to the setting of the element.  Check that the Trip, Pickup (and if selected, Alarm) LEDs are on, and one of the following is displayed: LATCHED: 5th Harmonic Level or OPERATED: 5th Harmonic Level  Reduce the 5th harmonic component until the element resets. The reset level should be 97% of the operate level.  Reset indicators and clear messages.  Repeat the above steps with a fundamental current level below the threshold setting.  Ensure that the element does not operate.  For timing tests, simulate an operating condition as above and apply suddenly to the relay and measure the operating time. The time should be the same as the setting in the element.
