RADISYS A6K-RSM-J工控DCS系统自动化设备

产品详细资料
捡拾器液位 在禁用间隔计时器的情况下，施加电流信号并增加其幅值，直到跳闸继电器（以及所有选定的辅助继电器）工作。 将测量的操作水平与S4元件进行比较 相位OC W1相位INST OC 1 W1 PHASE INST OC 1 PICKUP设定值。 检查元件运行时跳闸、拾取和相位A（C）指示灯是否点亮。 检查是否显示以下消息之一：LATCHED a:W1 Phase Inst OC 1或OPERATED a:W1相位仪表OC 1减小电流，直到元件复位。复位电平应为操作电平的97%。当元件复位时，如果W1 Phase INST OC 1 TARGET（W1相位安装OC 1目标）被选择为Latched（锁定），则跳闸和相位LED应保持点亮。否则，只有跳闸指示灯应保持亮起。 重置指示灯并清除信息。7.5.5.4操作时间 使用图7-9中所示的设置：第7-25页的常规测试设置，并启用间隔计时器，将电流水平设置为元件工作水平的1.5倍。 通过闭合双极开关来突然施加电流。 记录操作时间，并将其与S4元素进行比较 相位OC W1相位INST OC 1 W1 PHASE INST OC 1 DELAY设定点值。7.5.5.5 B相和C相元件如果A相元件运行正确且符合规范，则对绕组1的B相和C相位重复上述测试的拾取水平部分。对于相位B，X=H2，Y=G2。对于相位C，X=H3，Y=G3。显示的信息应发生变化，以指示正确的相位、绕组和运行元件。
Pickup level  With the interval timer disabled, apply the current signal and increase its magnitude until the trip relay (and all selected auxiliary relays) operate.  Compare the measured operating level against the S4 ELEMENTS  PHASE OC  W1 PHASE INST OC 1  W1 PHASE INST OC 1 PICKUP setpoint.  Check that Trip, Pickup, and Phase A(C) LEDs turn on when the element operates.  Check that one of the following messages is displayed: LATCHED a: W1 Phase Inst OC 1 or OPERATED a: W1 Phase Inst OC 1Reduce the current until the element resets. The reset level should be 97% of the operate level. When the element resets, the Trip and Phase LEDs should remain on if the W1 PHASE INST OC 1 TARGET was selected as Latched. Otherwise, only the Trip LED should stay on.  Reset indicators and clear messages. 7.5.5.4 Operating Time  Using the setup shown in FIGURE 7–9: General test setup on page 7– 25 and the Interval Timer enabled, set the current level to 1.5 times the operating level of the element.  Apply current suddenly by closing the double-pole switch.  Record the operate time and compare it to the S4 ELEMENTS  PHASE OC  W1 PHASE INST OC 1  W1 PHASE INST OC 1 DELAY setpoint value. 7.5.5.5 Phase B and C Elements If the phase A element performed correctly and met specifications, repeat the pickup level portion of the above test for phases B and C of winding 1. For phase B, X = H2 and Y = G2. For phase C, X = H3 and Y = G3. The displayed message should change to indicate the correct phase, winding, and element that operated.
主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
