Radisys 46088101数字量控制板卡

产品详细资料
Dia（直径）列下的框表示诊断状态。如果它打开，则表明发生了致命的以太网端口错误，或者网络上有重复的IP地址。如果闪烁，则表示存在非致命的网络错误。关闭表示没有错误。此处显示逻辑输入1至16的状态和设定点访问跳线。当SETPOINT ACCESS STATE（设定点访问状态）为“Open”（打开）时，无法从前面板更改设定点。FLEXLOGIC EQN ERROR（FLEXLOGIC EQN错误）值显示FLEXLOGIC中发生的错误源™ 方程式BAD SETTINGS ERROR（不良设置错误）值显示在分配设置点值时产生不良设置的原因。对于每个监测绕组，a、B、C相的基频幅值和相位角以及接地电流每半个周期重新计算一次，用于差动和过电流保护。根据这些值，计算中性、正、负、零序以及差动、限制和接地差动电流。为了便于阅读，这些信息大约每秒显示和更新两次。显示了绕组1相a、B和C、中性点和接地的基频电流大小。A相的电流角总是设置为0°，因为它被用作所有其他电流的参考，无论是测量的还是推导的。还显示了指定绕组的大指定负载和平均相电流。所有正序、负序和零序分量的相位角均参考绕组1相A电流。此处显示了绕组1、2和3的正序电流幅值和相位值。
The box under the Dia column indicates the diagnostic status. If it is on, then either a fatal Ethernet port error has occurred or there is a duplicate IP address on the network. If blinking, then there is a non-fatal network error. Off indicates no errors.The states of logic inputs 1 through 16 and the setpoint access jumper are displayed here. Setpoints cannot be changed from the front panel when the SETPOINT ACCESS STATE is “Open”.The FLEXLOGIC EQN ERROR value displays the source of the error occurring in a FlexLogic™ equation. The BAD SETTINGS ERROR value displays the cause of a bad setting made while assigning setpoint valuesFor each monitored winding, the fundamental frequency magnitude and phase angle of phase A, B, C and ground currents are recalculated every half-cycle for use in differential and overcurrent protection. From these values, neutral, positive, negative and zerosequence as well as differential, restraint and ground differential currents are calculated. These are displayed and updated approximately twice a second for readability.The fundamental frequency current magnitudes for winding 1 phases A, B, and C, neutral, and ground are shown. The current angle for phase A is always set to 0° as it is used as reference for all other currents, both measured and derived. The maximum specified load and average phase current are also shown for the specified winding.All positive-, negative-, and zero- sequence component phase angles are referenced to the winding 1 phase A current The positive-sequence current magnitudes and phase values for windings 1, 2, and 3 are shown here.
主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
