OKUMA BL3-D100A工控DCS系统

产品详细资料
注意：在极少数情况下，I/A系列系统或DNBI电缆中的故障可能会导致ACM发生故障。如果以下步骤无法解决问题，请验证DNBI电缆是否正确连接并处于良好工作状态。如果问题仍未解决，请联系全球客户支持（GCS）中心寻求帮助。更换EICM本程序介绍如何更换增强型智能通信模块（EICM）。如果故障指示灯点亮或通过指示灯熄灭，则应更换模块。有关指标信息，请参阅第316页的EICM指标。步骤1断开与故障模块相关的所有通信电缆。2松开模块的可伸缩紧固件，抓住紧固件，将模块滑出机箱。3在更换模块上，将TriStation接口开关和RS-232/422/485开关设置为与故障模块相同的设置。4将更换模块插入机箱插槽。将模块推入，直到它牢固地固定在机箱中。5将更换模块的可伸缩紧固件拧紧至10英寸磅。6验证通过指示灯是否在大约一分钟内点亮，激活指示灯是否会在一到两分钟内点亮。7重新连接所有通信电缆。8在故障模块上，识别型号和序列号。联系全球客户支持（GCS）中心以获取退货材料授权（RMA）编号。然后将模块返回到Invensys进行维修。警告当您从系统中卸下模块时，通过EICM的所有通信都会停止。
Note In rare cases, faults in the I/A Series system or in the DNBI cables might cause an ACM to fault. If following the above steps does not solve the problem, verify that the DNBI cables are properly connected and in good working order. If the problem is still not solved, contact the Global Customer Support (GCS) center for assistance.Replacing EICMs This procedure explains how to replace Enhanced Intelligent Communication Modules (EICMs). If the Fault indicator is on or the Pass indicator is off, the module should be replaced. For indicator information, see EICM Indicators on page 316. Procedure 1 Disconnect all communication cables associated with the faulty module. 2 Undo the retractable fasteners of the module, grasp the fasteners, and slide the module out of the chassis. 3 On the replacement module, set the TriStation interface switches and the RS-232/422/485 switches to the same settings as on the faulty module. 4 Insert the replacement module into the chassis slot. Push the module in until it is firmly seated in the chassis. 5 Tighten the retractable fasteners of the replacement module to 10 inch-pounds. 6 Verify that the Pass indicator goes on within about one minute, and the Active indicator goes on within one to two minutes. 7 Reconnect all the communication cables. 8 On the faulty module, identify the model and serial numbers. Contact the Global Customer Support (GCS) center to obtain a Returned Material Authorization (RMA) number. Then return the module to Invensys for repair. WARNING All communication through an EICM ceases when you remove the module from the system.
主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!

●使用前:

在操作和维护，安装设备之前，请阅读并严格遵守安全相关的信息。

Read and strictly follow safety-related information before operatingmaintainingand installing equipment.

●使用者要求:

必须从事安装，组装或维护设备等相关工控电气机械以及其他相关技术的人员。

Must be engaged in the installation,assembly or maintenance of equipment and other related industriacontroeectrica machinery and other related technica personne.应用范围:

应用于品牌本系列工业以及生产生活自动化设备产品。

Used in the brand of this series of industriaand production automation eauipment products

适用于场景:系统集成，非标定制，产线升级改造，原设备电气替换等等。

Suitable for scenarios:system integration,non-standard customizationproduction line upgrading and transformation,electrical replacement of original equipment,etc.

●操作人员:

应该由本品牌专业培训操作员来安装、操作和维修设备。专业人员具有技术能力强，熟悉安全信息和安全实施:

熟悉设备的安装加工、操作和维护:熟悉处理所有的潜在危险情况。

Equipment should be installed,operated and maintained by trained operators from the brand

●危险情况

警告

.请注意使用人员的人身安全。

●除了产品特性以及功能，还需了解产品的使用寿命环境。

●充分学习产品使用手册，否则非专业人员可能会造成人身危险。

Study the product instruction manual thoroughlyotherwise it may cause personal danger to non-professionals.

●服务行业

适用水泥，木业，石业，橡胶，石油，化工，发电，环保，水处理，制冷，交通，钢铁，食品，饮料，船舶，制冷等行业

Applicable to cementwood,stone,rubber,petroleumchemical, power generation
