3623和3623T规格本表列出了3623和3663T型号的规格，这两种型号是标称电压为120 VDC的TMR监控数字输出模块。3623型具有1500 VDC的点隔离；3623T型具有2500 VDC的点隔离。注意：Invensys强烈建议您在选择3623T型模块用于具有以下任何一种情况的应用之前进行兼容性测试：•现场接线长度超过328英尺（100米）•表不是双绞线•智能设备、闪光灯或喇叭等非典型负载颜色代码钢蓝色输出信号数量16，常用推荐电压范围90–150 VDC大电压160 VDC逻辑功率<10瓦额定电流，大0.8安培/点，4安培浪涌/10ms小所需负载30mA对负载的泄漏电流4mA，大保险丝（现场终端）每个输出1个（1安培，快动）状态指示器：打开或关闭状态每个点1个状态指示器：模块状态通过，故障，激活状态指示灯：现场警报电源、负载/保险丝（每点1个）点隔离：3623 1500 VDC小点隔离：3633T 2500 VDC小短路检测阈值处于关闭状态<24Ω输出诊断故障覆盖率b：大输出切换率小输出切换率每100 ms不适用诊断故障持续时间c大2 ms，500μsec典型导通电压降：在背板上，带外部终端，10英尺电缆带外部终端。99英尺电缆在250mA时典型值<1.0 VDC，在1A时大值<1.0 VDC<2.0 VDC，典型值@250mA，大值<2.5 VDC，在1A<2.5 VDC典型值@250 mA，大值<6.0 VDC
3623 and 3623T Specifications This table lists the specifications for Models 3623 and 3623T, which are TMR Supervised Digital Output Modules with a nominal voltage of 120 VDC. Model 3623 has a point isolation of 1,500 VDC; Model 3623T has a point isolation of 2,500 VDC. CAUTION Invensys highly recommends that you perform compatibility testing before selecting the Model 3623T module for use in applications that have any of the following: •Field wiring lengths over 328 feet (100 meters) •Table that is not twisted pair •Atypical loads such as smart devices, strobe lights, or klaxons Color code Steel blue Number of output signals 16, commoned Recommended voltage range 90–150 VDC Maximum voltage 160 VDC Logic power < 10 watts Current ratings, maximum 0.8 amps/point, 4 amps surge/10 ms Minimum required load 30 mA Leakage current to load 4 mA, maximum Fuses (field termination) 1 per output (1 amp, fast-acting) Status indicator: On or Off state 1 per point Status indicator: Module status Pass, Fault, Active Status indicator: Field alarma Power, Load/Fuse (1 Per Point) Point isolation: 3623 1,500 VDC minimum Point isolation: 3623T 2,500 VDC minimum Short-circuit detection threshold in Off state < 24 Ω Output diagnostic fault coverageb: Maximum output toggle rate Minimum output toggle rate Every 100 ms Not applicable Diagnostic glitch durationc 2 ms maximum, 500 μsec typical On-state voltage drop: At backplane With external termination, 10-foot cable With external termination, 99-foot cable < 1.0 VDC typical @ 250mA, < 1.0 VDC maximum @ 1A < 2.0 VDC typical @ 250mA, < 2.5 VDC maximum @ 1A < 2.5 VDC typical @ 250mA, < 6.0 VDC maximum @ 1A
