Radisys UIMC III-1轴运动控制板

产品详细资料
本标准特别规定，在1-2-3的源相序分别连接到标记为1、2和3的变压器绕组的情况下，建立相位关系。IEC标准60076-1（1993）规定，三相的端子标记遵循国家惯例。绕组之间的相位关系显示为铭牌上的指定符号，并且可能有相量图。在本标准中，绕组的任意标记显示为I、II和III。本标准特别指出，相位关系是针对I-II-III的源相序连接到标记为I的变压器绕组的条件建立的，在描述绕组相位关系时必须说明源相序，因为当相序改变时，这些关系会改变。下面的例子显示了为什么会发生这种情况，使用IEC命名法中描述为“Yd1”或GE Multilin命名法中定义为“Y/d30”的变压器。上图显示了变压器内的物理连接，该物理连接在三角形绕组中产生相位角，该相位角滞后于相应的Y形绕组30°。绕组电流也被识别。注意，三角形绕组的总电流由一个方程描述。现在假设一个具有ABC序列的源分别连接到变压器端子ABC。平衡负载的电流如下所示。
This standard specifically states that the phase relationships are established for a condition where the source phase sequence of 1-2-3 is connected to transformer windings labeled 1, 2 and 3 respectively. IEC standard 60076-1 (1993) states that the terminal markings of the three phases follow national practice. The phase relationship among the windings is shown as a specified notation on the nameplate, and there may be a phasor diagram. In this standard the arbitrary labeling of the windings is shown as I, II, and III. This standard specifically states that the phase relationships are established for a condition where a source phase sequence of I - II - III is connected to transformer windings labeled I, II and III respectively The source phase sequence must be stated when describing the winding phase relationships since these relationships change when the phase sequence changes. The example below shows why this happens, using a transformer described in IEC nomenclature as “Yd1” or in GE Multilin nomenclature as “Y/d30.”The above figure shows the physical connections within the transformer that produce a phase angle in the delta winding that lags the respective wye winding by 30°. The winding currents are also identified. Note that the total current out of the delta winding is described by an equation. Now assume that a source, with a sequence of ABC, is connected to transformer terminals ABC, respectively. The currents that would be present for a balanced load are shown below.
主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
